2. Key Features

• Redundancy Support: Dual‑module hot‑swap configuration; no system shutdown required for replacement.

• Wide Input Range: Accepts 100–240 V AC (50/60 Hz) or 24 V DC input for global compatibility.

• Multiple Outputs: Supplies +5.1 V DC (15 A), +12 V DC, and +24 V DC to system components.

• High Efficiency: Up to 90% efficiency to reduce heat and energy consumption.

• Built‑in Protections: Overvoltage, overcurrent, short‑circuit, and overtemperature protection.

• EMI Shielding: Metal enclosure minimizes electromagnetic interference.

3. Specifications

• Model: PW301

• Type: Modular power supply for DCS

• Input Voltage: 100–240 V AC ±10% (50/60 Hz) or 24 V DC

• Output Voltages: +5.1 V DC (15 A), +12 V DC, +24 V DC

• Max Output Power: 60 W

• Ripple & Noise: <1 mV p‑p

• Regulation: ±0.5% (line and load)

• Operating Temperature: 0°C to +50°C

• Storage Temperature: −20°C to +70°C

• Humidity: 5%–95% RH (non‑condensing)

• Dimensions (W×H×D): 32.8 × 130 × 144.5 mm

• Weight: 0.3 kg

• Installation: Rack‑mount in FCU cabinet slots

4. Installation and Configuration

• Mounting: Install in designated FCU cabinet slots; supports single or dual (redundant) setup.

• Wiring: Connect AC input to rear screw terminals; route DC output to backplane.

• Redundant Operation: Install two PW301 modules for automatic load sharing and failover; hot‑swap faulty module without interrupting system power.

5. LED Indicators

• POWER (Green): On when input power is normal.

• READY (Green): On when all outputs are stable and within regulation.

• FAULT (Red): On if overvoltage, overcurrent, short circuit, or overtemperature occurs; flashes during fan failure.

6. Diagnostic and Protection

• Self‑Diagnostics: Continuously monitors input voltage, output voltages, current, and internal temperature.

• Fault Response: Shuts down outputs and triggers FAULT LED during protection events; latches fault status until power cycle.

• Alarm Reporting: Sends fault data to FCU and HMI for maintenance alerts.

7. Application

• Systems: CENTUM CS3000, CENTUM VP DCS.

• Applications: Petrochemical, power generation, refining, water treatment, and other process industries.

• Usage: Powers FCUs, I/O modules, ESB bus couplers (e.g., EC401‑50), and communication modules in control cabinets.
