1. Product Overview
2. Key Features
40‑Channel Multi‑I/O: 26 inputs + 14 outputs for comprehensive wind turbine monitoring/control.
Universal Analogue Inputs: Software‑configurable for ±10 V, ±20 mA, or RTD (PT100) sensors.
Optical Isolation: Full galvanic isolation for all I/O channels (noise immunity & safety).
On‑Board Processor: Fast local sampling and scaling, reducing controller load.
EtherCAT Communication: High‑speed, real‑time data exchange with AWC 500.
Extended Temperature: –40°C to +75°C (–40°F to 167°F) for nacelle deployment.
LED Status Indicators: Tri‑colour RUN LED for EtherCAT state and module health.
Wind Turbine Certified: IEC 61400, DNV‑GL, CE, EMC compliant.
3. Technical Specifications
3.1 Electrical Ratings
| Parameter | Specification |
|---|---|
| Model | IOM5‑1 |
| System Compatibility | AWC 500 Wind Turbine Controller (EtherCAT) |
| Input Channels (26) | |
| – Analogue Inputs (AI) | 4 × universal (±10 V / ±20 mA) |
| – Temperature Inputs (TI) | 6 × RTD (PT100, 3‑wire) |
| – Digital Inputs (DI) | 12 × optically isolated (24 VDC) |
| – Frequency/Digital Inputs (FI/DI) | 4 × pulse (0–10 kHz, 24 VDC) |
| Output Channels (14) | |
| – Analogue Outputs (AO) | 4 × ±20 mA (12‑bit resolution) |
| – Digital Outputs (DO) | 10 × relay (250 VAC / 5 A) |
| Control Supply | 24 VDC ±20% (18–32 VDC), ≤12 W |
| Isolation | 2.5 kV AC (1 min) all I/O to bus |
| Resolution (Analogue) | 12‑bit (AI/AO) |
| Accuracy (Analogue) | ±0.15% FS @ 25°C |
3.2 Environmental & Mechanical
| Parameter | Specification |
|---|---|
| Operating Temperature | –40°C to +75°C (–40°F to 167°F) |
| Storage Temperature | –40°C to +85°C (–40°F to 185°F) |
| Humidity | 0–95% RH non‑condensing |
| Vibration | 2–13.2 Hz: ±1 mm; 13.2–200 Hz: ±1.0 g |
| Enclosure | IP20 (front), IP00 (rear) |
| Dimensions (W×H×D) | 240 × 160 × 50 mm (6HE, double euro) |
| Weight | Approx. 1.4 kg |
| Mounting | 19” DIN rack (AWC 500 nacelle cabinet) |
4. Application Scope
Wind Turbine Control: Pitch control, yaw control, and hydraulic system monitoring.
Condition Monitoring: Vibration, temperature (gearbox, generator, bearings), and speed sensing.
Safety Systems: Emergency stop, overspeed protection, and fire alarm interfacing.
Power Quality: Grid voltage/current monitoring and reactive power control.
Remote Monitoring: SCADA data acquisition for wind farm operation.
5. Installation & Wiring
5.1 Installation Requirements
Mounting: Install in an AWC 500 19” rack (vertical); ensure ≥50 mm clearance for ventilation.
Environment: Avoid direct sunlight, moisture, corrosive gases, and excessive vibration.
ESD Protection: Use an anti‑static wristband when handling the module (static‑sensitive components).
5.2 Module Addressing
EtherCAT Node Address: Set via AWC 500 software (1–31); no hardware switches.
5.3 Terminal Wiring (Simplified)
| Terminal Group | Description | Wire Gauge |
|---|---|---|
| Power | ||
| 1–2 | 24 VDC (+/−) | 1.5 mm² |
| 3 | Chassis ground (PE) | 2.5 mm² |
| Analogue Inputs (AI1–AI4) | ||
| 4–7 | ±10 V / ±20 mA | 1.0 mm² |
| Temperature Inputs (TI1–TI6) | ||
| 8–19 | PT100 (3‑wire) | 1.0 mm² |
| Digital Inputs (DI1–DI12) | ||
| 20–31 | 24 VDC logic | 1.0 mm² |
| Frequency/DI (FI1–FI4) | ||
| 32–35 | 0–10 kHz pulse | 1.5 mm² |
| Analogue Outputs (AO1–AO4) | ||
| 36–39 | ±20 mA | 1.5 mm² |
| Digital Outputs (DO1–DO10) | ||
| 40–49 | Relay (NO/COM) | 2.5 mm² |
AI Configuration: Use DEIF Utility Software to set AI type (voltage/current); no DIP switches required.
Shielded Cables: Use twisted‑pair shielded cables for analogue/frequency signals; ground shield at one end only.
Terminal Torque: Tighten terminals to 0.8–1.0 Nm to avoid loose connections.
6. Front Panel & Operation
6.1 Front Panel Layout
Tri‑Colour RUN LED (EtherCAT & Service State):
Off: INIT or no power.
Slow blinking green: Pre‑operational.
Slow blinking orange/red: Pre‑operational (module selected).
Single flash green: Safe‑operational.
Single flash orange/red: Safe‑operational (module selected).
EtherCAT Port: For connection to AWC 500 controller.
6.2 Startup & Configuration
Power On: Apply 24 VDC; RUN LED lights (off → blinking green).
EtherCAT Connection: Connect cable to AWC 500; LED blinks green (pre‑operational).
Module Configuration: Use DEIF Utility Software to set AI type, scaling, and DO logic.
System Recognition: AWC 500 detects IOM5‑1; LED flashes green (safe‑operational).
Parameter Setup: Configure fault thresholds, filter settings, and safety interlocks.
Operation: RUN LED single flash green = normal operation; I/O active per system logic.
7. Safety Precautions
High Voltage Hazard: Only qualified electricians may install/service; disconnect all power before wiring.
ESD Risk: Static electricity can damage the PCB; use anti‑static protection when handling.
Relay Output Caution: DO relays switch high voltages; ensure load ratings are not exceeded.
No Unauthorised Modification: Do not open the enclosure; tampering voids the warranty.
Environmental Limits: Do not operate outside –40°C to +75°C; avoid condensation.
8. Maintenance & Storage
8.1 Regular Maintenance (Every 6 Months)
Visual Inspection: Check for loose terminals, damaged wiring, or corrosion.
Cleaning: Wipe the front panel with a dry cloth; do not use liquid cleaners.
LED Check: Verify RUN LED operates correctly per EtherCAT state.
Channel Test: Use DEIF Utility Software to test AI/AO/DI/DO/FI accuracy and functionality.
Cable Tightness: Re‑tighten terminals to 0.8–1.0 Nm.
8.2 Storage Guidelines
Condition: Store in original anti‑static packaging at 10–30°C, 30–70% RH.
Environment: Keep dry; avoid direct sunlight and extreme temperatures.
Duration: Shelf life ≤2 years; inspect for ESD damage before use if stored longer.
9. Troubleshooting
| Fault Phenomenon | Possible Cause | Solution |
|---|---|---|
| RUN LED Off | No 24 VDC supply / blown fuse | Check power wiring; replace 3 A fuse |
| RUN LED Blinks Green Continuously | EtherCAT communication fault / wrong node address | Verify cable; check address in AWC 500 |
| RUN LED Blinks Red/Orange | Module hardware fault / overvoltage | Cycle power; contact DEIF support |
| Analogue Input Inaccurate | Software config mismatch / noisy signal | Correct AI type in Utility Software; use shielded cables |
| Frequency Input No Reading | Incorrect voltage range / wiring fault | Verify FI input voltage (24 VDC); check terminals 32–35 |
| Digital Output Not Activating | Overload / wiring fault | Check load; verify DO terminal connections |
10. Warranty & Disclaimer
Model: IOM5‑1 High‑Flexibility 40‑Channel I/O Module.
Warranty Period: 24 months from delivery date under normal installation and use.
Warranty Exclusions: Damage from misuse, overvoltage, lightning, water ingress, or unauthorised modification.
Specifications Subject to Change: Manufacturer reserves the right to update specifications without prior notice.
Liability Limitation: Manufacturer is not liable for indirect or consequential damages.
Documentation Version: 1.0 (2026); latest manual available at www.deifwindpower.com.
