T9191

The T9191 is a tall blanking cover for unused I/O slots in the AADvance T9100 6U chassis, specifically for positions without a terminal assembly (FTA) installedRockwell Automation. It fills empty module slots to maintain safety, mechanical integrity, EMI shielding, and airflow in the chassis. It is a passive, non‑electronic accessory (no logic, no I/O, no communications) used in system build, expansion, or maintenance to cover vacant slots and prevent accidental contact with live backplane components.

Description


1. Introduction

The T9191 is a tall blanking cover for unused I/O slots in the AADvance T9100 6U chassis, specifically for positions without a terminal assembly (FTA) installedRockwell Automation. It fills empty module slots to maintain safety, mechanical integrity, EMI shielding, and airflow in the chassis.
It is a passive, non‑electronic accessory (no logic, no I/O, no communications) used in system build, expansion, or maintenance to cover vacant slots and prevent accidental contact with live backplane components.

  • Function: Tall blanking cover for empty T9100 I/O slots (no FTA)

  • Compatibility: AADvance T9100 6U chassis (all slots 1–12)

  • Material: High‑impact polycarbonate, UL 94 V‑0 flame retardant

  • Installation: Snap‑fit, tool‑free (hot‑swap compatible)

  • Color: Dark gray (matches T9xxx modules)

  • Safety: Prevents contact with live backplane; dust/DEbris protection

2. Product Overview

The T9191 is a single‑width, 6U tall plastic cover that installs in any vacant slot of the T9100 chassis where no I/O module and no FTA are presentRockwell Automation. Unlike standard short blanking covers, the T9191 is “tall” to fully cover the vertical opening when no terminal assembly is fitted.
Key features:

  • Tall profile: Full 6U height for slots without FTARockwell Automation

  • Snap‑fit mounting: Tool‑free insertion/removal; aligns with chassis guides

  • EMI shielding: Maintains chassis EMI integrity when slots are empty

  • Airflow management: Preserves designed cooling airflow across all slots

  • Safety compliance: Blocks access to live backplane connectors; meets IP20 for cabinet installations

  • Harsh environment: Robust polycarbonate withstands industrial temperature, vibration, and dust

Common applications:

  • T9100 chassis unused I/O slots (no FTA installed)

  • System build/configuration (before adding I/O modules)

  • Maintenance (temporary removal of I/O without FTA)

  • Spare slot coverage in ESD/BMS/SIL 3 systems


3. Specifications

3.1 Mechanical

  • Form Factor: T9100 chassis single‑width, 6U tall blanking cover

  • Dimensions (H × W × D): 266 mm × 31 mm × 25 mm (full height, same as T9xxx modules)

  • Weight: Approx. 0.15 kg

  • Mounting: Snap‑fit into T9100 chassis slot guides (slots 1–12)

  • Material: High‑impact polycarbonate, UL 94 V‑0 flame retardant

  • Color: Dark gray (RAL 7021 equivalent)

  • Profile: Tall (for positions without FTA)Rockwell Automation

3.2 Environmental

  • Operating Temperature: –40 °C to +70 °C (same as T9xxx modules)

  • Storage Temperature: –40 °C to +85 °C

  • Humidity: 5–95 % RH, non‑condensing

  • Vibration: 10–57 Hz ±0.10 mm; 57–150 Hz 1.5 g (no degradation)

  • Shock: 20 g, ½ sine wave, 11 ms (no damage)

3.3 Safety & Compliance

  • Protection: Prevents contact with live backplane circuits (IP20)

  • EMI: Maintains chassis shielding effectiveness

  • Flame Rating: UL 94 V‑0 (self‑extinguishing)

  • Approvals: CE (EMI/EMC), UL (flame)

4. Installation & Removal

  1. Insertion: Align T9191 with empty T9100 slot guides; push firmly until snap‑fit latches engage (click sound)

  2. Removal: Grasp front edge, pull outward firmly (no tools required)

  3. Hot‑Swap: Safe to install/remove while chassis is powered (no impact on system)

  4. Compatibility Note: Use T9191 for slots without FTA; use standard short cover if FTA is presentRockwell Automation

5. Ordering Information

  • T9191: AADvance Tall Blanking Cover (for I/O positions with no TA/FTA)Rockwell Automation

  • T9100: AADvance 6U/12‑slot safety chassis

  • T9xxx: AADvance I/O modules (T9110, T9100‑F2, etc.)

  • T98xx: AADvance FTA terminal assemblies
