General Information

• Model: 3612KPM

• Manufacturer: XYCOM Automation, Schneider Electric / Pro-face

• Product Type: 12.1 Inch Industrial Panel PC with Built-in Keypad and Mouse

• Series: 3600 Series

• Product Status: End of Life, only refurbished and used devices available

• Installation Type: Embedded panel mounting

• Approximate Weight: 11.3 kg

Display & Operation Unit

• Display Size: 12.1 inch industrial color TFT LCD

• Default Resolution: 800 × 600 SVGA

• Supported Resolution: Up to 1024 × 768 XGA

• Backlight: Long service life CCFL backlight

• Brightness: Industrial standard grade

• Touch Screen: Not equipped

• Operation Device: Integrated full 74 keys industrial membrane keypad and industrial mouse

System Hardware Configuration

• Central Processor: Intel Celeron 850MHz / Pentium III series industrial CPU

• Standard Memory: 256MB SDRAM

• Maximum Expandable Memory: 512MB

• Storage Device: Standard IDE hard disk, equipped with floppy drive and CD-ROM drive

• Video Control: Onboard industrial PCI graphics chip, 2MB video memory

• Expansion Slots: Half-length PCI slot, three-quarter length PCI slot, ISA slot and shared expansion slot

Power Supply Parameters

• Input Voltage: 115V / 230V AC automatic switching, 50/60Hz

• Built-in multiple protection: Over voltage, over current, short circuit and surge protection

External Interface

• Serial Interface: 1 × RS-232, 1 × RS-232/485 adaptive port

• Parallel Interface: 1 × standard printer parallel port

• Network Interface: 1 × 10/100Mbps Ethernet RJ45 port

• USB Interface: 2 × USB 1.1 communication ports

• PS/2 Interface: External keyboard and mouse expansion interface

• Audio Interface: Audio input, audio output and microphone interface

• VGA Interface: External monitor signal output port

Mechanical Specifications

• Front Panel Size: Standard industrial panel size

• Overall Depth: Industrial embedded installation size

• Front Panel Protection Level: NEMA 4/4X/12, IP65 fully sealed

• Equipment Shell: High strength industrial metal casing

Environmental Adaptability

• Operating Temperature Range: 0°C ~ +55°C

• Storage Temperature Range: -20°C ~ +60°C

• Working Humidity: 10% ~ 90% RH, non-condensing environment

• Vibration and Shock Resistance: Meet international IEC industrial environmental test standards

Compatible Operating Systems

• Applicable Systems: MS-DOS, Windows 98, Windows NT, Windows 2000

• Industrial Real-time Systems: QNX, VxWorks

Product Certifications

• Safety Certification: UL508, CE certification

• Explosion-proof Grade: UL Class I Division 2, Class II Division 2 hazardous area certification

• Electromagnetic Compatibility: FCC Class A, industrial EMC certification

Market Supply Situation

• Original new production has been completely stopped

• Main supply: Fully tested refurbished machines and original second-hand spare parts

• Recommended replacement model: Pro-face high-performance 12.1 inch industrial keypad panel computer
