1. General Information

• Model: 5019 / 5019T (T = Touch)

• Manufacturer: Xycom Automation (Pro‑face)

• Type: 19” SXGA TFT LCD Industrial Touch Monitor

• Mounting: Panel mount / VESA arm mount (100mm)

• Front Panel: NEMA 4/4X/12, IP65

• Rear: IP20

• Weight: 21 lbs (9.52 kg)

• Status: Current production / industrial replacement part

2. Electrical Specifications

• Input Voltage: 100–240 VAC, 50/60 Hz, 1.0 A max

• Optional: 24 VDC ±10%

• Power Consumption: ≤ 100 VA

• Certifications: UL, cUL, CE, FCC Class A, CB

• Hazardous Location: Class I/II, Division 2, Groups A–D, F–G; T4A

3. Display

• Panel: 19” TFT Color LCD

• Resolution: SXGA 1280 × 1024 @ 75 Hz

• Brightness: 300 nits (cd/m²)

• Contrast Ratio: 700:1

• Viewing Angle: 160° symmetrical (H/V)

• Color Depth: 16.7 million colors

• Scaler: Built‑in scaling engine (supports 640×480 / 800×600 up to SXGA)

4. Touch Screen (5019T)

• Type: 5‑wire analog resistive (standard)

• Interface: RS‑232 serial + USB

• Life: > 10 million touches

• Option: Capacitive touch

5. Video Inputs

• VGA: 15‑pin D‑sub (analog RGB)

• DVI‑D: Digital video

• Composite Video: RCA

• S‑Video: Mini‑DIN

6. Mechanical & Environmental

• Dimensions (W×H×D): 18.51” × 15.70” × 3.00” (470×399×76 mm)

• Operating Temp: 0 °C ~ +50 °C

• Optional Wide: –20 °C ~ +60 °C

• Humidity: 20%–80% RH, non‑condensing

• Vibration: IEC 60068‑2‑6 compliant

• Bezel: Standard black; stainless steel optional

7. Interfaces (Rear)

• Serial: RS‑232 (touch)

• USB: USB 2.0 ×2 (touch & peripheral)

• Video: VGA, DVI‑D, Composite, S‑Video

• Mount: VESA 100mm hole pattern
