K2-400
Model: K2-400
Brand: KEBA
Product Type: Industrial main control CPU unit
Application: Injection molding machine, mechanical automation, multi-axis motion control system
Installation: Standard cabinet rack installation
Protection Class: IP20
Description
1. General Information
Model: K2-400Brand: KEBAProduct Type: Industrial main control CPU unitApplication: Injection molding machine, mechanical automation, multi-axis motion control systemInstallation: Standard cabinet rack installationProtection Class: IP20
2. Electrical Parameters
Rated power supply: DC24V ±10%Operating current: 1.5A maxPower consumption: About 18WBuilt-in protection: over voltage, under voltage, over current, short circuit, reverse polarity and EMC anti-interference protection
3. System Performance
High speed industrial main control chipLarge capacity program memory and data storageSupport power off data saving functionFast system operation response, stable program operationSupport multi-task program parallel operation
4. Communication Interfaces
Built-in dedicated K-bus backplane busStandard Ethernet communication portSerial communication interface for program upload and downloadSupport connecting various KEBA series expansion I/O modules
5. Environmental Parameters
Operating temperature: 0℃ ~ +55℃Storage temperature: -40℃ ~ +85℃Working humidity: 5%~95%RH, non-condensingGood ventilation and heat dissipation required for long time running
6. Main Functions
Undertake whole machine automatic operation logic control
Real-time collection and processing of all field signal data
Accurate control of hydraulic, servo and all executive actions
Support equipment parameter setting, modification and storage
Built-in complete fault detection and alarm output function
Realize remote monitoring and system online debugging
7. Compatible Modules
Match DC162 series, FB201, E-16-DIGOUT/G, IC101 and other KEBA modulesCompatible with HRS series drive control modules
8. Installation Instruction
Cut off total power before installation and replacement
Insert the main control board into the card slot smoothly and fix tightly
Check bus contact and wiring correctness
Separate strong current and weak signal lines during wiring
Finish inspection then power on to test running status
9. Safety Notice
Only professional technicians can install, replace and debug this unit.Do not disassemble internal structure without permission.Use strictly within rated voltage and temperature range to extend service life.
