1. General Information

• Model: IC101

• Manufacturer: KEBA (Austria)

• Type: Industrial central control unit / PLC module

• Application: Injection molding machines, machine tools, automated production lines, motion control systems

• Mounting: Standard cabinet rail / rack mounting

• Protection Class: IP20

• Weight: ~0.8 kg

• Warranty: 12 months (new/refurbished available)

2. Electrical & Core Specifications

• Power Supply: DC 24V (19.2–30V DC, EN 61131-2)

• Processor: High-performance industrial CPU (ARM-based)

• Memory: On-board RAM/Flash for program & data storage

• Real-Time Clock: Battery-backed (for data retention)

3. I/O & Interfaces

• Digital I/O: Integrated high-speed inputs/outputs for sensors/actuators

• Analog I/O: 0–10V / 4–20mA for process signals

• Communication Ports:

  • Ethernet (TCP/IP, EtherCAT optional)

  • CANopen / Profibus DP (fieldbus)

  • Serial (RS-232/485) for HMI/debug

• Expansion Slots: For KEBA I/O modules (e.g., FB201, HRS series)

4. Control & Performance

• Control Modes: Sequential logic, motion control, PID regulation

• Motion Functions: Positioning, synchronization, servo drive control (compatible with HRS10102/HRS201)

• Programming: KEBA KeStudio / KeControl environment (IEC 61131-3 compliant)

• Scan Time: Fast cycle time for real-time applications

5. Environmental Conditions

• Operating Temp: 0°C ~ +55°C

• Storage Temp: -20°C ~ +70°C

• Humidity: 5%–95% RH, non-condensing

• Vibration/Shock: Compliant with EN 61131-2 (industrial grade)

6. Key Features

1. System Core: Manages entire machine logic, motion, and I/O coordination

2. Drive Compatibility: Works with KEBA HRS series drives (HRS10102/HRS201) & FB201 I/O module

3. Safety: Built-in safety functions (overload, overtemp, emergency stop)

4. Diagnostics: LED status indicators, fault logging, remote monitoring

5. Compact & Rugged: Industrial design for harsh factory environments

7. Installation & Safety

• Install only with power disconnected; use ESD protectionKEBA

• Mount on DIN rail; allow 50mm clearance for cooling

• Separate high-voltage power cables from low-voltage signal wiresKEBA

• Qualified personnel only for wiring, programming & commissioningKEBA
