1. General Information

• Model: CR‑092 (CR092)

• Brand: KEBA (Austria)

• Type: Compact PLC / Controller Module (for industrial automation, injection molding, machine control)

• Series: CR‑series (entry‑level / mid‑range, related to KeControl C2/K2‑200)

• Application: General machinery, plastic processing, conveyor systems, standard automation retrofits

• Status: Discontinued (only new surplus / refurbished available)

• Alternative: Often cross‑referenced with KEBA CP251/U or CP252/W (pin‑to‑pin compatible in many racks)

2. System Specifications

• CPU: 32‑bit real‑time industrial processor

• RAM: 8 MB (standard for CR/early CP series)

• Flash: 16 MB (program/data, power‑off retention)

• OS: KEBA proprietary real‑time multitasking OS

• Performance: Suitable for logic + basic motion control

3. Interfaces & Local I/O

• Local I/O:

  • 16 × Digital Inputs (24 VDC, sink/source)

  • 8 × Relay Outputs (250 VAC / 30 VDC, resistive load)

• Communication Ports:

  • Ethernet (RJ45, 10/100 Mbps)

  • RS‑232 (DB9, serial)

  • K‑Bus (KEBA backplane bus for I/O expansion)

  • Display/Panel port (DB15, for operator interface)

• Expansion: Connects to K2‑200 / KeConnect I/O modules via K‑Bus

4. Electrical Parameters

• Supply Voltage: 24 VDC ±10% (19.2–30 VDC)

• Max Current: 1.0 A

• Power Consumption: ~15 W

• Protection: Overvoltage, overcurrent, reverse polarity, EMC

5. Environmental & Mechanical

• Operating Temp: 0°C → +55°C

• Storage Temp: ‑40°C → +85°C

• Humidity: 5%–95% RH (non‑condensing)

• Protection Class: IP20 (cabinet mounting)

• Dimensions (H×W×D): 160 × 62 × 131 mm

• Weight: ~1.25 kg

6. Key Features

1. Cost‑effective controller for standard machine automation

2. Integrated I/O + Ethernet/RS‑232 reduces need for extra modules

3. K‑Bus expansion compatible with wide range of KEBA I/O

4. Rugged industrial design for shock/vibration environments

5. Drop‑in replacement for many older KEBA CR/CP modules in CC100 racks

7. Installation Notes

• Power off before insertion/removal

• Mount in standard KEBA CC100 series rack slots

• Use shielded cables for Ethernet/RS‑232

• Ensure cabinet ventilation; avoid continuous high temperature
