1006-403-1-00
Brand: SEW-EURODRIVE
Type: Single-phase AC Frequency Inverter
Model: 1006-403-1-00
Description
Brand: SEW-EURODRIVEType: Single-phase AC Frequency InverterModel: 1006-403-1-00
Basic Parameters
Rated Power: 0.75 kW
Input Power: Single-phase AC 230V, 50/60Hz
Rated Output Current: 4.6 A
Output Frequency Range: 0~400 Hz
Control Mode: V/F open-loop control
Standard Interface: RS485 communication port
Protection Class: IP20
Cooling Method: Natural air cooling
Operating Temperature: 0℃ ~ +50℃
Model Code Meaning
1006: 0.75kW power specification code403: 230V single-phase voltage grade1: Single-phase power input00: Standard factory configuration
Main Features
Compact size, easy installation and wiring
Built-in complete over-current, over-voltage and overload protection
Stable speed regulation performance, low operation noise
Simple parameter setting, convenient field debugging
Support terminal signal and communication remote control
Application
Suitable for speed regulation of small single-phase motors, widely used in small fans, water pumps, light-duty conveying and auxiliary automation equipment.
