UT150-1 Product Specification (English Version)

1. Product Overview

2. Core Functions

1. Multi-Type Signal Acquisition: 8 independent channels, supporting Thermocouples (J/K/T/E/N/R/S/B), RTDs (Pt100/Pt500/Ni100), and mV signals (±100mV).

2. Independent Signal Processing: Each channel features independent Cold Junction Compensation (CJC) and linearization algorithms for high accuracy across the full range.

3. High-Precision Conversion: Accurately converts analog temperature signals to digital for DCS monitoring, logic judgment, and process control.

4. Hardware Redundancy: Supports redundant configuration with seamless failover (<100ms) to prevent data loss and unplanned shutdowns.

5. Fault Diagnosis: Provides wire break detection, over-range alarms, and self-diagnostics for quick troubleshooting.

6. System Communication: Communicates with the main controller via the DCS backplane bus for data upload and command reception.



7.

3. Technical Specifications

3.1 Input Specifications

• Channels: 8 Differential Inputs

• Supported Signals:

  • Thermocouple: J, K, T, E, N, R, S, B

  • RTD: Pt100, Pt500, Ni100

  • Millivolt: ±100 mV

• Measuring Range:

  • Thermocouple: -200°C to +1370°C (depends on type)

  • RTD: -200°C to +850°C

• Accuracy: ±0.1% F.S. (Typical)

• Temperature Drift: < 0.01% Span/°C

• Response Time: < 500 ms (Programmable Filter)

3.2 Electrical & Physical

• Power Supply: 24 V DC (Backplane Powered)

• Power Consumption: < 15 W

• Dimensions: Standard Eurocard, approx. 233 × 160 × 20 mm

• Weight: Approx. 0.8 kg

• Mounting: 19" Rack Card Type

• Protection: IP20 (Cabinet Installation)

3.3 Environmental

• Operating Temp: -10°C to +55°C

• Storage Temp: -40°C to +85°C

• Humidity: 5%–95% RH (Non-condensing)

• EMC: Compliant with IEC 61000-4, stable in high EMI environments

3.4 Reliability & Certification

• MTBF: ≥ 100,000 Hours

• Safety Standard: IEC 61508 SIL 2

• Certifications: CE, UL, RoHS Compliant



•

4. Product Features

• Industrial High Precision: Independent channel processing and CJC ensure accurate measurements in extreme industrial environments.

• Wide Compatibility: Fully compatible with mainstream temperature sensors, eliminating the need for extra signal conditioners.

• Redundant Reliability: Hardware-level redundancy designed for critical temperature protection loops in boilers and turbines.

• Maintenance-Free: All-solid-state components, no moving parts, suitable for continuous operation.

• Hot-Swappable: Supports online replacement without system shutdown for easy maintenance.



•

5. Applications

• Power: Boiler, steam pipe, turbine, generator winding temperature monitoring.

• Oil & Gas: Refinery, chemical reactor, heat exchanger temperature control.

• Metallurgy: Blast furnace, converter, kiln temperature acquisition.

• Rail Transit: Traction converter, braking resistor temperature monitoring.



•

6. Ordering Information

• Model: UT150-1

• Packaging: Anti-static bag + Shockproof carton

• Warranty: 12 Months (New Original)

• Lead Time: 3–5 Days (In Stock)
