1. Product Overview

2. Product Version & Core Positioning

AS111-1 is a standard xenon strobe sounder beacon without rotating halogen lamp option. It adopts high-frequency xenon flash technology to deliver high-visibility visual warning, suitable for daily safety monitoring and emergency evacuation scenarios. The model supports mainstream industrial and fire system voltages, including DC24V, DC48V, AC115V and AC230V, fully compatible with global conventional fire alarm panels and industrial control power supply systems.

3. Full Technical Specifications

3.1 Audible Performance

• Maximum Sound Pressure Level: 100dB(A) @ 1 metre (±3dB tolerance)

• Programmable Tones: 64 built-in international standard industrial and fire alarm tones

• Compliance Standards: Compatible with PFEER, UKOOA, DIN and IMO standard alarm tone requirements

• Alarm Levels: Multi-stage graded alarm modes for normal warning, equipment fault and emergency danger

• Volume Control: Stepless adjustable volume to adapt to different site noise environments

• Synchronous Function: Automatic synchronous sounding for multiple networked devices

3.2 Visual Performance

• Light Source: High-efficiency industrial xenon strobe tube

• Flash Frequency: Standard fixed emergency flash rate for industrial safety alert

• Visibility: High luminous intensity with excellent penetration in dusty, smoky and outdoor bright-light environments

• Lens Colour Options: Red, Amber, Green, Blue, Clear for different hazard level identification

• Operational Stability: Stable intermittent flash output, long service life for continuous unattended operation

3.3 Electrical Parameters

• DC24V Version: Operating voltage 18–30Vdc, low power consumption, standard for fire alarm systems

• DC48V Version: Operating voltage 40–56Vdc, suitable for long-distance loop power supply

• AC115V / AC230V Version: Industrial AC power input, independent stable drive circuit

• Circuit Protection: Built-in reverse polarity protection, over-current protection and surge resistance

• Working Mode: Support continuous alarm and intermittent alarm output

3.4 Environmental & Structural Parameters

• Ingress Protection: IP65, fully dust-tight and waterproof, suitable for indoor and outdoor all-weather use

• Housing Material: High-strength flame-retardant engineering plastic, UV-stabilized, anti-aging and corrosion-resistant

• Lens Material: High-transmittance impact-resistant polycarbonate (PC)

• Operating Temperature: -40℃ ~ +70℃

• Storage Temperature: -45℃ ~ +75℃

• Relative Humidity: 95% RH non-condensing

• Cable Entry: Standard sealed waterproof gland for reliable wiring

• Structure Feature: Ultra-compact integrated design, lightweight and easy to install

4. Key Product Features

4.1 Dual Audible & Visual Warning

4.2 Flexible Programmable Alarm Logic

4.3 Multi-Unit Synchronous Operation

4.4 Industrial Grade Weather Resistance

4.5 Easy Installation & Low Maintenance

The compact lightweight body supports wall mounting and bracket mounting. Standard wiring terminals and simple internal configuration enable fast on-site installation and commissioning. The xenon light source features stable performance and low failure rate, requiring minimal daily maintenance and reducing long-term operational costs.

5. Certification & Compliance

6. Typical Applications

• Fire Safety Systems: Commercial building fire emergency alarm, smoke detection and heat detection linkage warning

• General Industrial Plants: Production line equipment fault alert, workshop abnormal status prompt

• Public Infrastructure: Power stations, water pumping stations, rail transit and municipal facility emergency warning

• Light Industrial & Warehouse: Storage area safety alert and personnel evacuation prompting

• Marine Auxiliary Areas: Ship cabin and platform public area conventional emergency alarm

7. Installation & Maintenance Guidelines

7.1 Installation Instructions

7.2 Daily Maintenance

Regularly clean dust and stains on the lens and housing surface to maintain optimal light transmittance and sound output effect. Periodically check wiring tightness and cable aging condition. The xenon light source requires no frequent replacement. Keep the device surface clean and unblocked to sustain stable warning performance throughout the service period.

8. Product Advantages

• Cost-Effective Performance: Balanced 100dB sound pressure and high-brightness xenon flash, fully meeting conventional industrial emergency warning demands

• Strong Compatibility: Full mainstream voltage options, compatible with global fire alarm and industrial control systems

• Rich Programmable Functions: 64 standard tones and multi-stage alarm modes to meet diverse industry standard requirements

• Rugged Environmental Adaptability: IP65 high protection grade and wide temperature range for indoor and outdoor harsh environments

• Low Operation Cost: Compact structure, simple installation and maintenance, stable long-term unattended operation

• Global Project Adaptability: Multiple international certifications, suitable for global engineering bidding and project delivery
