AH116-2 Industrial Combined Sounder Beacon Full Product Specification

1. Product Overview

2. Key Product Features

• High Audible Performance: High sound pressure level output with multiple international standard alarm tones, delivering long-distance sound penetration

• Multi-Stage Programmable Alarm: Supports 4 remote selectable alarm stages, flexible tone assignment for different hazard levels

• Automatic Synchronisation: Multi-unit synchronous flashing and sounding on networked systems, ensuring unified site-wide alarm signalling

• Daisy-Chain Wiring Support: Duplicate cable inlet and outlet terminals simplify series installation and reduce wiring workload

• Dual Mounting Options: Installable via external mounting lugs or internal BESA-compatible fixing holes for flexible on-site deployment

• Corrosion & Aging Resistance: Equipped with stainless steel fixings and UV-stabilized housing for long-term outdoor service

• Continuous Rated Operation: Designed for 24/7 continuous working status without overheating or performance degradation

• Customizable Configuration: Optional tropicalization treatment and customized tone/frequency settings for special project requirements

3. Technical Specifications

3.1 Audible Specifications

• Maximum Sound Pressure Level: Up to 116dB(A) @ 1 metre

• Tone Library: 45 built-in standard industrial & marine warning tones, compliant with mainstream international safety standards

• Alarm Stages: 4 remotely selectable independent alarm stages; any tone can be freely assigned to any stage

• Operation Mode: Continuous sound, intermittent sound, sweeping tone and emergency siren modes available

• Adjustment: On-site volume fine-tuning supported to adapt to different ambient noise environments




•

3.2 Visual Specifications

• Light Source Type: High-efficiency xenon flash tube, stable flashing and high visual recognition

• Effective Luminous Intensity: Standard 200cd effective intensity, excellent long-distance visibility

• Flash Rate: Standard industrial fixed flash frequency, stable and consistent warning rhythm

• Service Life: Flash tube maintains 70% luminous efficiency after 8 million flashes

• Lens Colour Options: Red, Amber, Yellow, Green, Blue, Clear, Opal for different hazard classification requirements

3.3 Electrical Specifications

• Operating Voltage Options: 12VDC, 24VDC, 115VAC, 230VAC (covers global industrial mainstream power supply systems)

• Working Mode: Continuous rated operation, stable output under long-term power-on state

• Circuit Protection: Built-in over-current, over-voltage and reverse polarity protection for anti-wiring damage

• Power Consumption: Optimized low-power design, suitable for battery-backup emergency systems

3.4 Environmental & Mechanical Specifications

• Ingress Protection Rating: IP56, fully dust-proof and waterproof against heavy rain and splashing water

• Housing Material: High-impact flame-retardant engineering plastic, UV-resistant, anti-aging and anti-corrosion

• Fixing Hardware: Full stainless steel fasteners, rust-proof for outdoor and marine environments

• Operating Temperature Range: -40℃ ~ +66℃

• Storage Temperature Range: -40℃ ~ +70℃

• Ambient Humidity: 95% RH non-condensing maximum

• Installation Method: Wall mounting, bracket mounting and column mounting applicable

4. Control & System Functions

4.1 Multi-Stage Graded Alarm

4.2 Multi-Unit Synchronous Linkage

4.3 Reliable Loop Adaptability

5. Certification & Compliance

The AH116-2 series complies with a full range of international safety and quality standards, including CE, UKCA certifications, and meets industrial fire protection, marine engineering and process control specification requirements. All products are tested in accordance with EN industrial signalling standards, applicable for global industrial, marine and commercial safety projects.

6. Typical Applications

• Industrial Plants: Workshop equipment failure alarm, production line abnormal warning, fire linkage alarm

• Petrochemical & Energy Industry: Toxic and harmful gas leakage warning, high-risk area safety alert

• Marine & Offshore Engineering: Ship cabin emergency alarm, offshore platform equipment fault signalling

• Commercial Buildings: Fire evacuation warning, security emergency alert

• Public Infrastructure: Power stations, pumping stations, traffic facilities emergency signal indication

7. Installation & Maintenance

7.1 Installation Guidelines
