2. Main Features

• Model: 6210008

• Type: Inductive proximity sensor

• Detectable materials: All metal objects

• Supply voltage: 10–30 V DC

• Output type: 3-wire DC

• Max load current: ≤ 200 mA

• Protection class: IP67 dustproof & waterproof

• Operating temperature: -25 °C ~ +70 °C

• Built-in reverse polarity, overvoltage and short-circuit protection

• Vibration resistant, shockproof, long service life

3. Safety Precautions

• Disconnect power before installation and wiring.

• Do not exceed rated voltage 10–30 V DC.

• Reverse power connection is strictly prohibited to prevent damage.

• Keep away from high-power motors and transformers to avoid magnetic interference.

• Do not disassemble or modify the sensor arbitrarily.

• Avoid mechanical impact, oil corrosion and long-term damp conditions.

4. Installation Guide

1. Fix the sensor with lock nut or mounting bracket.

2. Keep standard effective sensing distance from metal target.

3. Install perpendicular to the detected metal surface for best accuracy.

4. Do not place extra metal parts near the sensing head.

5. Arrange cables properly, avoid sharp bending and forced pulling.

5. Wiring Definition

• Brown : DC +10～30 V Power

• Blue  : DC 0 V Ground

• Black : Signal output

• Shield: Ground only at controller side

6. Operating Instructions

1. Wire strictly according to standard definition.

2. Power on, the sensor enters standby state.

3. When metal enters sensing range, indicator lights up and outputs signal.

4. When metal moves away, signal resets and indicator turns off.

5. Compatible with PLC, relay and automation controller input.

7. Troubleshooting

• No indicator light: Check power supply and wiring.

• Always output signal: Metal too close or surrounding metal interference.

• Unstable flashing: Loose wiring, vibration or voltage fluctuation.

• Light on but no output: Broken signal wire or damaged load.

8. Maintenance

• Clean dust and iron scraps on the sensing surface regularly.

• Check mounting tightness and cable aging periodically.

• Avoid long-term operation in high temperature and corrosive environment.

• Replace timely if shell crack or cable damage occurs.
