2. Main Features

• Model: 6200086

• Type: Inductive proximity sensor

• Detectable object: All metal materials

• Supply voltage: 10–30 V DC

• Output type: 3-wire DC

• Max load current: ≤ 200 mA

• Protection class: IP67 dustproof and waterproof

• Operating temperature: -25 °C ~ +70 °C

• Built-in reverse polarity, overvoltage and short-circuit protection

• Vibration resistant, shockproof and long service life

3. Safety Precautions

• Disconnect power before installation and wiring.

• Do not exceed rated voltage 10–30 V DC.

• Reverse power connection is strictly prohibited to avoid sensor burnout.

• Keep away from high-power motors, transformers and strong magnetic interference.

• Do not disassemble or modify the sensor structure privately.

• Avoid mechanical impact, oil pollution and long-term damp environment.

4. Installation Guide

1. Fix the sensor with locking nut or mounting bracket.

2. Maintain standard effective sensing distance from metal target.

3. Install perpendicular to the detected surface for best detection accuracy.

4. Do not place extra metal parts near the sensing head.

5. Route cable properly, avoid sharp bending and forced pulling.

5. Wiring Definition

• Brown  : DC +10～30 V Power

• Blue   : DC 0 V Ground

• Black  : Signal output

• Shield : Ground only at controller side

6. Operating Instructions

1. Complete wiring strictly in accordance with the definition.

2. Power on, the sensor enters standby working state.

3. When metal enters effective sensing range, indicator lights up and output signal acts.

4. When metal target leaves, output resets and indicator turns off.

5. It can be directly connected to PLC, relay and industrial controller input.

7. Troubleshooting

• No indicator light: Check power supply and wiring circuit.

• Always output signal: Metal target too close or ambient metal interference.

• Signal flickering unstably: Loose wiring, mechanical vibration or power fluctuation.

• Indicator on but no output: Signal wire breakage or load damage.

8. Maintenance

• Regularly clean dust and iron debris on the sensing surface with dry cloth.

• Periodically check mounting tightness and cable wear condition.

• Avoid long-term operation in high temperature and corrosive gas environment.

• Replace the sensor in time if shell crack or cable aging appears.
