AR-101

作者：小编 更新时间：2026-05-20 点击数：




General Description

The AR-101 (H/U) is a miniature embedded RFID access controller/reader by SOYAL, supporting dual-frequency (125 kHz / 13.56 MHz) card reading. It features compact size, flush mounting, and integrated access control functions for doors, elevators, cabinets, and industrial equipment.

Models

  • AR-101-H: Standalone controller with door contact input, alarm functions

  • AR-101-U: Reader/controller with RS-485 / Wiegand switchable interface

Specifications

Electrical

  • Input Voltage: 9–24 V DC

  • Power Consumption: < 1 W (AR-101-U); < 3 W (AR-101-H)

  • Frequency: 125 kHz (EM) / 13.56 MHz (Mifare)

  • Reading Distance: 1–3 cm

Mechanical

  • Dimensions: 37 × 37 × 31 mm

  • Weight: ~40 g

  • Housing: ABS, IP55 (dust/water resistant)

  • Mounting: Flush-mount, panel installation

Environmental

  • Operating Temperature: -20 °C to +60 °C

  • Storage Temperature: -30 °C to +70 °C

  • Humidity: 5%–95% RH, non-condensing

Key Features

  • Dual-frequency RFID: Reads 125 kHz EM and 13.56 MHz Mifare cards

  • User Capacity: 1,024 users; 1,200 event logs (AR-101-H)

  • DIP Switch Selectable: RS-485 or Wiegand (26/34 bits) output

  • Dual-color LED & Buzzer: Green for valid access, red for invalid/alert

  • Master Card Function: Quick enrollment/deletion without keyboard

  • Alarm Input (AR-101-H): Door open too long / forced entry alarm

  • Relay Outputs: Door lock, alarm, security trigger signals

  • Watchdog: Prevents system hanging

Interface & Wiring

AR-101-U Terminals

  1. Vin: 9–24 V DC

  2. GND: Ground

  3. WG-D0: Wiegand Data 0

  4. WG-D1: Wiegand Data 1

  5. RS485-A: RS-485 A

  6. RS485-B: RS-485 B

  7. Lock Relay: NO/COM/NC

  8. Alarm Relay: NO/COM/NC

AR-101-H Additional

  • Door Contact Input (NC/NO)

  • Egress Button Input

Installation

  1. Mount the unit into a standard 37×37 mm cutout

  2. Secure with mounting screws

  3. Connect power (9–24 V DC) and ground

  4. Wire Wiegand/RS-485 to controller or host

  5. Connect lock, alarm, and door contact (if applicable)

  6. Set DIP switches for interface mode (RS-485 / Wiegand)

  7. Enroll master card, then user cards

Operation

  • Standby: Green LED slow flash

  • Valid Card: Green LED on, buzzer beep once, lock relay activate

  • Invalid Card: Red LED flash, buzzer beep twice

  • Door Open Too Long: Red LED flash, buzzer continuous beep

  • Forced Entry: Red LED on, buzzer continuous beep, alarm relay activate

Compliance

  • CE, RoHS, FCC certified

  • Compliant with EN 60839-11, EN 50131-1

Package Contents

  • AR-101-H/U main unit

  • Wiring harness

  • Mounting screws

  • User manual

Optional Accessories

  • Stainless steel mounting panel

  • Wiegand keyboard (AR-WG-KEYBOARD)

  • Relay output module (AR-821-RB)

  • Master cards (2 pcs)

Note: This is a compact professional access controller. Exact functions may vary by firmware version. Refer to SOYAL’s official datasheet for full details.
