140XCP51000 Product Details

(Note: The 40XCP51000 you queried should be 140XCP51000, which is a placeholder fake module of Schneider Electric Modicon Quantum series)

1、 Basic Information

Manufacturer: Schneider Electric

Product Series: Modicon Quantum (Quantum Series PLC)

Model: 140XCP51000

Product type: Dummy Module (placeholder module/slot cover)

Functional positioning: Blank filling of discrete I/O modules, protecting the backplane and maintaining system integrity

2、 Appearance and Structure

Color: Industrial Grey

Material: industrial grade high-strength plastic, anti-aging, oil stain resistant

Size: Single slot standard size, compatible with Quantum series I/O rack

Weight: Approximately 0.23kg (0.50lbs), lightweight and easy to install

Installation method: Directly insert into the Quantum standard backplane, tool free insertion and removal

3、 Technical specifications

Occupation slot: 1 standard I/O slot

Anti vibration: Peak value of 1.5mm within the frequency range of 10-57Hz (continuous vibration)

Impact resistance: 15g (11ms pulse impact), suitable for industrial strong vibration environment

Working temperature: 0 ° C to+60 ° C (industrial standard temperature range)

Storage temperature: -40 ° C to+85 ° C (wide temperature storage, suitable for extreme environments)

Compatibility: All Modicon Quantum series I/O racks and backplanes

4、 Core functions and purposes

Vacancy filling: Unused I/O slots in the PLC rack must be equipped with this module to prevent the backplane from being exposed, dust/foreign objects from entering, and accidental short circuits.

System integrity: Ensure impedance matching of backplane signals to avoid system instability, communication interference, and errors caused by empty slots.

Protection and Dust Prevention: Covering empty slots, protecting backplane contacts, extending equipment lifespan, and reducing maintenance costs.

Compatible with Discrete I/O: Designed specifically for Discrete I/O slots, not for analog or special function slots

5、 Application scenarios

Factory automation production line (automotive, electronics, food packaging)

Process Control Systems (Water Treatment, Chemical, Energy)

Infrastructure (building automation, rail transit)

Any industrial control scenario using Modicon Quantum PLC

6、 Ordering and Identification

EAN code: 3595861135284

Alias/Easy to mix models: 140XCP5100O, 140XCP510O0, L40XCP51000, etc. (all of which are the same product)

7、 Installation precautions

Power off before installation to avoid static electricity damaging the backplate

Insert vertically into the slot and lock it when you hear a "click" sound

When disassembling, gently pull out the buckles on both sides by pinching them, and do not pull or tug violently
