General Description

Part Number

Key Specifications

• Processor: 400 MHz Freescale MPC5200 PowerPC

• DRAM Memory: 128 MB

• Nonvolatile Flash Storage: 2 GB

• Operating System: VxWorks real-time OS

• Ethernet: 1 × 10/100 Mbps port

• Serial Port: 1 × RS-232

• USB: 1 × USB 2.0 port

• Power Input: 9–35 VDC

• Operating Temperature: -40 °C to +70 °C

• Mechanical: Fanless, rugged industrial design

• Compatibility: Works with CompactRIO reconfigurable chassis and C Series I/O modules

Main Features

• Deterministic real-time performance with VxWorks for closed-loop control and high-speed automation

• Fanless rugged construction for harsh industrial and outdoor environments

• Onboard 2 GB flash memory for local program storage and data logging

• Integrated Ethernet, serial, and USB ports for communication and peripheral connection

• Fully programmable with LabVIEW for custom control, acquisition, and monitoring applications

• Wide temperature tolerance and industrial-grade reliability

Applications

• Industrial real-time machine control and automation

• High-speed data acquisition and condition monitoring

• Structural health monitoring, vibration and dynamic signal measurement

• Mobile and vehicle-mounted embedded control systems

• Process control, energy equipment monitoring, and test stand automation

• Maintenance and replacement of legacy CompactRIO systems

Recommended Replacement
