cFP‑2110 (National Instruments)

Compact FieldPoint Real‑Time Controller (EOL, mid‑range in 21xx series)

1. General Description

2. Part Number

• Model: cFP‑2110

• NI PN: 777317‑2110, 190187G‑01

3. Key Specifications

• Processor: 188 MHz real‑time CPU

• Memory:

  • RAM: 128 MB DRAM (double cFP‑2100)

  • Non‑volatile: 64 MB onboard

  • Expansion: CompactFlash slot (max 512 MB)

• I/O Slots: 8 hot‑swappable cFP modules

• Communication:

  • Ethernet: 10/100 Mbps RJ45 (Modbus TCP, NI protocols)

  • Serial: 2 × RS‑232 DB9 (Modbus RTU/ASCII)

• OS: LabVIEW Real‑Time (preinstalled, v8.6–v201x)

• Programming: LabVIEW RT, NI MAX

• Power: 11–30 VDC (24 V nominal), redundant input support

• Power Consumption: ~6.5 W + I/O load

• Operating Temperature: ‑20 °C to +55 °C (standard); ‑40 °C to +70 °C (extended)

• Mounting: DIN rail / panel mount

• Status: Discontinued / EOL

4. Main Features

• Upgraded I/O & memory: 128 MB RAM + 2 serial ports for more complex logic and serial devices

• All‑in‑one: controller + 8‑slot backplane

• Standalone operation: runs without host PC

• Hot‑swap I/O: replace modules online

• Industrial ruggedness: isolation, 2300 V transient protection, Class I Div 2 certified

5. Applications

• Industrial distributed real‑time control

• Factory automation & process monitoring

• Remote data acquisition & standalone logging

• Environmental & building automation

• Legacy Compact FieldPoint system upgrades
