PU516 3BSE013064R1
PU516 / 3BSE013064R1 English Technical Parameters & Usage Instructions & Precautions
Basic Information
Manufacturer: ABB
Product Type: MB300 PCI Engineering Interface Board (AC 800M Series)
Part Number Combination: PU516 (Module Assembly), 3BSE013064R1 (Official Factory Part Number)
Application: ABB AC800M control system, MB300 masterbus debugging, upper computer engineering connection, controller program download, real-time data monitoring
Description
PU516 / 3BSE013064R1 English Technical Parameters & Usage Instructions & Precautions
Basic Information
Manufacturer: ABB
Product Type: MB300 PCI Engineering Interface Board (AC 800M Series)
Part Number Combination: PU516 (Module Assembly), 3BSE013064R1 (Official Factory Part Number)
Application: ABB AC800M control system, MB300 masterbus debugging, upper computer engineering connection, controller program download, real-time data monitoring
1. PU516 Technical Parameters
Bus Standard: 32-bit PCI Bus, 33 MHz Clock Frequency
Onboard Memory: 16 MB High-speed Data Cache Memory
Communication Interface: 1 × MB300 Port + 1 × RS232 Serial Port
Bus Transmission Rate: Max 1.0 Mbps MB300 Bus Speed
Supply Voltage: 5 VDC PCI Slot Power Supply
Current Consumption: ≤ 0.32 A @5VDC
Total Power Dissipation: ≤ 1.60 W
Compatible Controller: PM150V08, CI547 MB300 Communication Module
Isolation Voltage: 1500 Vrms Galvanic Isolation
Working Temperature: -20℃ ~ +60℃
Storage Temperature: -40℃ ~ +85℃
Ambient Humidity: 5%~95% RH (Non-condensing)
Protection Grade: IP20
2. Internal Circuit & Function Description
Core Function: MB300 bus signal conversion, upper computer data transmission, controller program downloading and system debugging
Data Processing: High-speed data caching, real-time signal parsing, bus communication acceleration processing
Compatibility Design: Special engineering card for MB300 bus system, matched with old-generation AC800M rack
Anti-interference: Industrial EMI&EMC anti-surge and high-frequency interference suppression circuit
Protection Mode: Overvoltage, overcurrent, static electricity and reverse connection protection
Structure: Standard PCI slot board, industrial-grade PCB, conformal coating anti-corrosion treatment
3. Usage Instructions
Installation: Install into industrial computer PCI slot; fix the board card with locking screws.
Wiring: Use dedicated MB300 shielded twisted-pair cable to connect CI547 communication module.
Debugging: Install dedicated driver; match station address for MB300 bus communication.
Operation: Real-time upload of controller operating data; support online program modification and monitoring.
Maintenance: Regularly clean gold finger dust; check cable connection tightness every six months.
4. Important Precautions
Do not install in humid, condensed water, dusty and corrosive gas environments.
Keep away from high-power interference sources to avoid MB300 communication packet loss.
Cut off computer power before plugging and unplugging the PCI board.
Prohibit abnormal voltage access on bus port to prevent internal communication chip damage.
Avoid severe vibration and mechanical impact during transportation and installation.
Ensure industrial computer heat dissipation to prevent board card crash and data delay.
Unauthorized disassembly of internal components is strictly prohibited.
5. General Technical Characteristics
Certification: CE, UL, RoHS
Installation Method: Industrial Computer PCI Slot Mount
