PM150V08 3BSE009598R1
Basic Information
Manufacturer: ABB
Product Type: Central Processor CPU Module (AC 800M Series)
Part Number Combination: PM150V08 (Module Assembly), 3BSE009598R1 (Official Factory Part Number)
Application: ABB AC800M Controller Rack, main logic operation, industrial process control, MB300 bus coordination, matched with CI547 communication submodule
Description
Basic Information
Manufacturer: ABB
Product Type: Central Processor CPU Module (AC 800M Series)
Part Number Combination: PM150V08 (Module Assembly), 3BSE009598R1 (Official Factory Part Number)
Application: ABB AC800M Controller Rack, main logic operation, industrial process control, MB300 bus coordination, matched with CI547 communication submodule
1. PM150V08 Technical Parameters
Core Processor: Industrial High-speed Central Processing Unit
Dynamic RAM: 8 MByte User Application Memory
External Storage: Support Flash Memory Program Card Expansion
Power Supply: Powered by Rack Backplane
Current Consumption: 0.85 A @5VDC
Total Power Dissipation: ≤ 4.20 W
Bus Interface: Built-in MB300 Masterbus Interface
Execution Cycle: Minimum 10 ms Logic Scan Cycle
Isolation Voltage: 2000 Vrms Galvanic Isolation
Working Temperature: -25℃ ~ +60℃
Storage Temperature: -40℃ ~ +85℃
Ambient Humidity: 5%~95% RH (Non-condensing)
Protection Grade: IP20
2. Internal Circuit & Function Description
Core Function: Main program logic calculation, data processing, bus resource management, cooperate with CI547 for MB300 communication
System Control: Real-time task scheduling, inter-submodule data interaction, fault diagnosis and system monitoring
Expansion Design: Compatible with SC510/SC520/SC520M carrier boards and all AC800M submodules
Anti-interference: Industrial EMI&EMC anti-surge and strong electromagnetic interference suppression circuit
Protection Mode: Overvoltage, overcurrent, short circuit and temperature overheating protection
Structure: Standard rack CPU card, high-reliability PCB, conformal coating anti-corrosion treatment
3. Usage Instructions
Installation: Standard controller rack slot mounting; install before all submodules, keep horizontal placement.
Wiring: No external signal wiring; rely entirely on backplane bus for internal data transmission.
Debugging: Download system firmware and user program via Control Builder software; verify MB300 bus communication.
Operation: Observe CPU running LED indicators; monitor scan cycle and system load in real time.
Maintenance: Regularly clean surface dust; check rack backplane contact condition every six months.
4. Important Precautions
Do not install in humid, condensed water, dusty and corrosive gas environments.
Keep away from high-power electromagnetic interference equipment to avoid logic calculation error.
Cut off all power supply before insertion, removal and module replacement operations.
Prohibit hot swapping during system running to prevent CPU program loss and chip damage.
Avoid severe vibration and mechanical impact during transportation and installation.
Ensure cabinet ventilation to prevent CPU overheating and system crash.
Unauthorized disassembly and firmware modification are strictly prohibited.
5. General Technical Characteristics
Certification: CE, UL, RoHS
Installation Method: Controller Rack Slot Mount
