CI535V30 3BSE022162R1
Basic Information
Manufacturer: ABB
Product Type: SPA & Modbus TCP Communication Submodule (AC 800M Series)
Part Number Combination: CI535V30 (Module Assembly), 3BSE022162R1 (Official Factory Part Number)
Application: ABB AC800M Controller Rack, SPA bus system, Modbus TCP/Ethernet communication, third-party instrument connection, industrial network data transmission
Description
Basic Information
Manufacturer: ABB
Product Type: SPA & Modbus TCP Communication Submodule (AC 800M Series)
Part Number Combination: CI535V30 (Module Assembly), 3BSE022162R1 (Official Factory Part Number)
Application: ABB AC800M Controller Rack, SPA bus system, Modbus TCP/Ethernet communication, third-party instrument connection, industrial network data transmission
1. CI535V30 Technical Parameters
Communication Protocol: SPA Bus + Modbus TCP/IP Dual Protocol
Channel Configuration: 1 Ethernet Port + 1 SPA Bus Interface
Interface Standard: RJ45 Ethernet Interface, Isolated SPA Terminal Interface
Ethernet Baud Rate: 10/100 Mbps Auto Adaptation
Power Supply: Powered by Rack Backplane (No External Power Required)
Current Consumption: 0.22 A @5VDC
Total Power Dissipation: ≤ 1.10 W
Transmission Distance: Max 1500 Meters (SPA Bus Cable)
Max Node Quantity: Up to 64 SPA Bus Station Nodes
Isolation Voltage: 2000 Vrms Galvanic Isolation
Working Temperature: -20℃ ~ +60℃
Storage Temperature: -40℃ ~ +85℃
Ambient Humidity: 5%~95% RH (Non-condensing)
Protection Grade: IP20
2. Internal Circuit & Function Description
Core Function: SPA bus signal transmission, Modbus TCP Ethernet communication, network data parsing and industrial equipment interconnection
Signal Processing: Network signal encoding, decoding, data buffering and industrial noise filtering
Dual Protocol Design: Support simultaneous SPA bus and Ethernet TCP communication mode
Anti-interference: Industrial EMI&EMC anti-surge and electromagnetic interference suppression circuit
Protection Mode: Overvoltage, overcurrent, static and reverse polarity protection
Structure: Small submodule card, high-density PCB, conformal coating anti-corrosion treatment
3. Usage Instructions
Installation: Insert into SC510 / SC520 / SC520M carrier board slot; horizontal installation inside control cabinet.
Wiring: Use standard shielded Ethernet cable for RJ45 port; dedicated twisted-pair cable for SPA bus wiring.
Debugging: Set IP address and SPA station parameters via Control Builder software.
Operation: Observe communication status LED; monitor network link and bus data transmission in real time.
Maintenance: Regularly clean dust; check cable fastening and shielding grounding condition every six months.
4. Important Precautions
Do not install in humid, condensed water, dusty and corrosive gas environments.
Keep away from high-power frequency converters to avoid network signal attenuation.
Cut off all power supply before insertion, removal and wiring operations.
Prohibit abnormal voltage access on communication port to prevent internal network chip damage.
Avoid severe vibration and mechanical impact during transportation and installation.
Ensure cabinet ventilation to prevent communication timeout caused by high temperature.
Unauthorized disassembly of internal components is strictly prohibited.
5. General Technical Characteristics
Certification: CE, UL, RoHS
Installation Method: Submodule Plug-in Mount
