2. General Description

3. Key Features

• NetCon Protocol Compliance: Native support for Woodward NetCon serial communication

• Precision Length: 10 feet (3 meters) exact length for standard system layouts

• Full Shielding: Twisted‑pair + overall shield for EMI/RFI immunity

• Molded Connectors: Factory‑terminated, lockable connectors (no field wiring)

• Galvanic Isolation: Reduces ground loops and electrical interference

• Industrial Durability: Oil, chemical, and abrasion‑resistant outer jacket

• Plug‑and‑Play: Direct connection to Woodward 505‑series and NetCon devices

• Wide Temperature: −40 °C to +85 °C operating range

• Certified Quality: CE, UL, RoHS compliant

4. Technical Specifications

• Model: 5416-190

• Manufacturer: Woodward (USA)

• Type: NetCon Serial I/O Communication Cable

• Length: 10 ft (3 m)

• Conductor: 2×24 AWG twisted pair

• Shielding: Foil + braid (100% coverage)

• Connectors: Woodward proprietary NetCon connectors (molded)

• Jacket Material: Industrial PVC (oil/chemical resistant)

• Voltage Rating: 300 Vdc

• Current Rating: 1 A max

• Operating Temperature: −40 °C to +85 °C

• Weight: Approx. 0.23 kg (0.5 lbs)

• Certifications: CE, UL, RoHS

• Compatibility: 505, 505E, 505XT, NetCon I/O modules, 5415‑series converters

5. Applications

• Turbine Control Systems: Connecting 505‑series governors to I/H converters (5415‑851/852/856/858/966)

• NetCon System Expansion: Linking master controllers to remote I/O chassis

• Power Generation: Steam/gas turbine governor communication

• Oil & Gas: Compressor and gas turbine control networking

• Industrial Retrofits: Upgrading legacy Woodward systems with modern NetCon cabling

6. Ordering Information

• Part Number: 5416-190

• Description: Woodward 5416-190 NetCon Serial I/O Cable, 10 ft (3 m), Shielded
