PRD-PB805EDD-00

Kollmorgen SERVOSTAR PB Series Digital Servo Drive

1. General Description

2. Model Definition

• PRD: Kollmorgen SERVOSTAR PB servo drive series

• P: Compact low-profile hardware platform

• B: DC battery power input type

• 805: Max 80 VDC input, 5 A continuous current

• E: Enhanced feedback configuration

• DD: Dual digital input and output expansion

• 00: Standard factory version without customized modification

3. Technical Specifications

Power Input

• Input Voltage: 24 VDC ~ 80 VDC

• Max Overvoltage Limit: 90 VDC

• Undervoltage Protection: 20 VDC

Output Performance

• Continuous Output Current: 5 Arms

• Peak Output Current: 10 Arms

• Overload Capacity: 2 times short-time overload

• Rated Matched Motor Power: Within 250 W

Control and Feedback

• Control Modes: Torque mode, Speed mode, Position mode

• Supported Feedback: Incremental encoder, resolver

• Control Command: ±10 V analog signal, pulse and direction

• Communication Interface: RS-232 / RS-485

Protection Functions

• Over-current, over-voltage, under-voltage, over-temperature and short circuit protection

• Support external regenerative braking resistor

• Standard industrial safety protection design

Environmental and Mechanical

• Protection Class: IP20

• Cooling Method: Passive heat dissipation, fanless design

• Operating Temperature: 0 °C ~ +45 °C

• Storage Temperature: -20 °C ~ +70 °C

• Installation: Standard cabinet mounting

4. Key Features

• Low voltage DC wide range input, suitable for battery powered equipment

• Fanless passive cooling, compact structure

• Support encoder and resolver dual feedback

• Expanded dual digital I/O interface for flexible system control

• Multiple motion control modes for different automation requirements

• Stable operation, low noise and high cost performance

5. Compatible Motors

• Kollmorgen AKM series low voltage small power servo motors

• Kollmorgen Silverline S series 24–80 VDC brushless servo motors

• Other general low voltage DC brushless servo motors within 250 W

6. Application Fields

• AGV and mobile robot equipment

• Medical instruments and laboratory automation

• Small engraving machines and portable CNC equipment

• Mini packaging and electronic assembly automation

• All kinds of 24–80 VDC low voltage industrial control systems
