PRD-JW60R00Z-06

Kollmorgen SERVOSTAR CD Series Digital Servo Amplifier

1. General Description

2. Model Breakdown

• PRD: SERVOSTAR CD series

• J: High-power chassis (60A class)

• W: 230VAC universal hardware (1φ/3φ)

• 60: 60A continuous current (top power rating)

• R: Resolver feedback

• 00: Standard I/O & no fieldbus

• Z: Special firmware variant

• 06: Custom build + extended safety/options

3. Key Specifications

Power Input

• Voltage: 200–240 VAC, 1φ/3φ

• Frequency: 50/60 Hz

• DC Bus: 90VDC (undervoltage) / 430VDC (overvoltage)

Output

• Continuous: 60 Arms

• Peak: 120 Arms (2× overload, 500ms)

• Rated power: 11 kVA (45°C)

• Matched motor power: 6–11kW (230V)

Control & Feedback

• Modes: Torque / Speed / Position

• Feedback: Resolver (R); compatible with incremental/absolute encoders

• Command: ±10V analog, pulse/direction

• Communication: RS-232/485 (no SERCOS)

Protection & Safety

• Overcurrent, overvoltage, undervoltage, overtemperature (80°C trip), short circuit, overload

• Regenerative braking (external ERH resistor)

• Extended safety I/O (06 version)

Mechanical & Environmental

• Enclosure: IP20 (cabinet mount)

• Cooling: Forced air

• Operating temp: 5°C to +45°C

• Storage temp: 0°C to 70°C

• Heat dissipation: ~380W

4. Key Features

• 60A continuous / 120A peak for high-power, high-torque applications

• Resolver feedback (rugged, reliable for harsh environments)

• Standard analog/pulse command + RS-232/485 communication

• 06 custom build with enhanced safety and firmware

• Heavy-duty industrial protection and noise immunity

5. Compatible Motors

• Kollmorgen AKM high-power series (230V, 6–11kW)

• Kollmorgen Silverline H series (H-6xxx / H-8xxx)

• Other 230VAC, 6–11kW brushless servo motors (resolver feedback)

6. Applications

• Large CNC machining centers, heavy-duty milling machines

• High-force gantry systems, material handling

• High-torque robotics, special heavy machine tools

• Heavy packaging, printing, and textile machinery

7. Notes

• Legacy product: SERVOSTAR CD is discontinued; replacement is AKD-P060 (60A class)

• Setup software: MOTIONLINK (legacy)
