6SM27M-4000-G
6SM27M-4000-G is a small permanent magnet synchronous servo motor from Kollmorgen Seidel, Germany, also marked as 6SM27M-4.000-G.
Description
6SM27M-4000-G is a small permanent magnet synchronous servo motor from Kollmorgen Seidel, Germany, also marked as 6SM27M-4.000-G.
1. Main Parameters
Model：6SM27M-4000-G
Rated Power：0.13 kW (130 W)
Rated Torque：0.32 Nm
Rated Speed：4000 rpm
Rated Voltage：250 V
Rated Current：0.80 A
Protection Class：IP64
Flange：55 mm square
Shaft Diameter：9 mm (with keyway)
Weight：approx. 1.1 kg
Suffix -G：Built-in power-off brake
2. Model Definition
6SM：Seidel servo motor series
27：Stator outer diameter 27 mm
M：Medium frame / medium inertia
4000：Rated speed 4000 rpm
-G：Integrated holding brake (spring-applied, power released)
3. Typical Applications
Small automation equipment, precision positioningSemiconductor & electronic devices, medical equipmentRobot joints, small conveyor systems
4. Matching Servo Drive
Compatible with Kollmorgen AKD series servo drives (such as AKD2G)
