PR9268/301-000 (EPRO/Emerson High-Temperature Type Bearing Vibration Sensor)

PR9268/301-000 is a high-temperature version of an inductive magnetic-electric bearing vibration sensor (bearing vibration), specially designed for high-temperature conditions ranging from -20℃ to +200℃. It has excellent low-frequency performance and high sensitivity, and is compatible with the TSI system.

Model Disassembly (9268/301-000)

9268: EPRO Electric Vibration Sensor Series

30: High-temperature type (-20℃ to +200℃), sensitivity 28.5 mV/mm/s, low frequency 4Hz to 1000Hz

1: Standard length 5m armored cable

000: Standard configuration (Harting connector, non-explosion-proof)

Core parameters (official)

Measurement object: Absolute vibration (velocity) of bearing housing

Principle: Electromagnetic induction, passive, no power supply required

Sensitivity: 28.5 mV/mm/s (±5%)

Frequency response: 4Hz～1000Hz (±3dB)

Range: ±1500 μm (peak-to-peak 3000 μm)

Operating temperature: -20℃～+200℃ (long-term)

Protection level: IP65 (better than 20 series)

Cable: 5m armored shielded, resistant to high temperature

Installation: Vertical / Horizontal, deviation ≤ ±10°

Shell: Stainless steel, corrosion-resistant

Key differences from 20 series (such as 201/202)

30 series (301-000): +200℃ high temperature, IP65, stainless steel shell, 5m armored

20 series (201/202): +100℃, IP55, aluminum alloy shell, 8m armored / ordinary

Compatible accessories

Direct compatibility: MMS3120, MMS6210, MMS6000 series cards

Application scenarios: High-temperature fans, boiler induced draft fans, high-temperature pumps, turbine high-temperature bearings, etc. for vibration monitoring

Differences in the same model (300/301/302)

9268/300-000: 17.5 mV/mm/s, 4Hz～1000Hz, 5m armored

9268/301-000: 28.5 mV/mm/s, 4Hz～1000Hz, 5m armored (high temperature, high sensitivity)

9268/302-000: 28.5 mV/mm/s, 4Hz～1000Hz, 8m armored
