9200-06110 (Honeywell EPRO CON021 Front End)

9200-06110 is a Honeywell (formerly German EPRO) CON021 series electromagnetic eddy current front end, used for non-contact shaft vibration / displacement / eccentricity monitoring, compatible with the PR642x series probes, 10-meter cable, non-explosion-proof.

Model breakdown

9200: CON021 series

06: Standard type (non-explosion-proof)

110: Compatible with 10-meter probe cable total length, standard configuration

(No suffix letters, equivalent to N, standard version)

(No suffix letters, equivalent to N, standard version)

Core parameters

Power supply: -24VDC (-18 to -30VDC), ≤80mA

Output: -4 to -20V (linear range), superimposed with vibration AC signal

Frequency response: 0 to 10kHz (-3dB)

Adapter probe: PR6423/6424/6425/6426 full series of eddy current sensors

Accuracy: with PR6423 ≤ 1.0%, PR6424 ≤ 1.5%

Operating temperature: -20℃ to +60℃

Protection / Installation: IP20, DIN rail installation

Terminal definition (5 pins)

1: -24V power supply negative

2: 0V power ground

3: Signal output (to MMS monitoring card)

4: Probe core wire

5: Probe shielding layer

Model differences (same series)

9200-06110: Standard type, 10m cable, non-explosion-proof

9200-06103N: Standard type, 10m cable, non-explosion-proof (internal version difference)

9200-00061N: Standard type, 6m cable, non-explosion-proof

9200-02061N: Explosion-proof type (Ex ib IIC T6), 6m cable

Typical accessories

Probe: PR6424/006-030 (eddy current sensor)

Preamplifier: 9200-06110 (CON021)

Monitoring module: 9100-03047-01 (MMS3120)
