Product Specification: X20AC0SR1

1. General Information

• Manufacturer: B&R Industrial Automation

• Part Number: X20AC0SR1

• Product Type: X20 System Accessory – Right End Cover & Locking Plate

• Product Series: B&R X20 Distributed I/O System

• Certification: CE, UKCA, RoHS Compliant

• Product Status: Active mass production

• Application Scope: Matching termination accessory for X20 bus base and I/O module assembly

2. Product Overview

3. Technical Specifications

3.1 Mechanical Parameters

• Installation Position: Right end of X20 I/O station

• Matching Standard: Universal for all standard X20 bus base modules and I/O slice modules

• Mounting Method: Tool-free snap-on installation

• Material: High-strength flame retardant thermoplastic, UL 94 V-0 fire rating

• Color: B&R standard industrial orange

• Weight: Approximately 0.01 kg

• Structure Feature: Integrated positioning buckle and anti-lock structure

3.2 Environmental Characteristics

• Operating Temperature Range: -25°C ~ +60°C

• Storage Temperature Range: -40°C ~ +85°C

• Relative Humidity: 5% ~ 95% RH, non-condensing

• Vibration Resistance: Meet IEC 60068 industrial vibration standard

• Protection Level: Assist the whole X20 assembly to maintain IP20 protection grade

3.3 Compliance Standard

• CE / UKCA certified

• RoHS environmental protection compliant

• Industrial low smoke and halogen-free material standard

4. Key Features

• Professional right-end mechanical termination for X20 I/O assembly

• Integrated locking function to fix the rightmost module and prevent loosening under vibration

• Dustproof and insulated sealing design to avoid dust and accidental contact exposure

• Tool-free snap installation, fast assembly and convenient maintenance

• Flame retardant and high toughness plastic material, suitable for long-term harsh industrial environment

• Uniform appearance and size, consistent with X20 series module overall style

• Perfectly matched with X20AC0SL1 left end cover for complete end protection

• Maintenance-free design, no daily adjustment and maintenance required

5. Typical Application

• Standard finishing installation of X20 I/O station in industrial control cabinet

• Mechanical anti-loosening protection for X20 module combination

• Isolation and dust protection at the right end of bus base module

• Supporting standard wiring and cabinet layout specification requirements

• Matching use in packaging machinery, process automation, logistics handling and other X20 system scenarios

6. Compatibility

• Compatible with all X20 bus base modules: X20BM11, X20BM15, X20BB80 and other series

• Suitable for all X20 digital input/output, analog, communication and functional modules

• Supporting matching accessory: X20AC0SL1 (Left end cover locking plate)

7. Installation Instruction

8. Reliability and Support

• Designed for 24/7 long-term continuous industrial application

• Follow B&R official standard warranty terms

• Long-term stable supply and technical support available

• Fully passive mechanical accessory, no aging failure risk under normal use.
